Cornell Iron Works, Inc. Grilles
Cornell Iron Works, Inc. logo

Cornell Iron Works, Inc.

Founded in 1828, Cornell manufactures a complete line of high quality Closure Products including rolling service doors, fire-rated doors, counter shutters and security grille products for commercial, industrial, institutional and retail use. Products are supplied through a network of authorized installing door distributors. ISO 9001:2015 registered, Cornell endeavors to provide exceptional product quality, design flexibility and superior support services to our customers. Please not that all CAD drawings provided are for a specific size. Doors and Grilles are 10’ x 10’ Counter Doors are 6’ x 4’ If specific dimensions are required, please visit the drawing generator available on our website.

Cornell Iron Works, Inc. logo

Cornell Iron Works, Inc.

Click to Call

24 Elmwood Avenue, Crestwood Industrial Park, Mountaintop, PA, 18707

Website

Download files for this product
Log in or create a free account to continue
  • Free, unlimited downloads
  • All formats: CAD, Revit, 3D, Specs
  • Manufacturer-provided, up-to-date files
Grilles preview 1
Grilles - Between Jambs - Right Hand - Crank - Tube Mount (Part A)
Grilles preview 1
DWG 1:1 Preview (Imperial)
Grilles

Grilles - Between Jambs - Right Hand - Crank - Tube Mount (Part A)

Need to securely separate two spaces but still need airflow and visibility?  Our Rolling Security Grilles are your answer. Our durable Rolling Security Grilles keep areas off-limits, require little to no maintenance and can be configured to meet your desired aesthetic. Custom built to an exact opening size, the commercial-duty design is durable, requires little-to-no maintenance and offers ease of repair with readily available parts. Install these overhead grilles behind storefront glass, at service window openings, in schools, malls, restaurants, healthcare settings and more.We offer several different security grille models, with different material options. Multiple opening sizes, as well as straight block or staggered brick patterns make the rolling grille variations practically unlimited. Our security grilles can be powder coated in nearly 200 stock colors as well as custom options and upgrades such as flame retardant polycarbonate inserts to prevent theft of small articles.
Grilles

Grilles - Between Jambs - Right Hand - Crank - Tube Mount (Part A)

Need to securely separate two spaces but still need airflow and visibility?  Our Rolling Security Grilles are your answer. Our durable Rolling Security Grilles keep areas off-limits, require little to no maintenance and can be configured to meet your desired aesthetic. Custom built to an exact opening size, the commercial-duty design is durable, requires little-to-no maintenance and offers ease of repair with readily available parts. Install these overhead grilles behind storefront glass, at service window openings, in schools, malls, restaurants, healthcare settings and more.We offer several different security grille models, with different material options. Multiple opening sizes, as well as straight block or staggered brick patterns make the rolling grille variations practically unlimited. Our security grilles can be powder coated in nearly 200 stock colors as well as custom options and upgrades such as flame retardant polycarbonate inserts to prevent theft of small articles.
