Postal Products Unlimited, Inc. 550 Series Private Use Mailboxes
Postal Products Unlimited, Inc. logo

Postal Products Unlimited, Inc.

Postal Products Unlimited, Inc. is the industry leader in the manufacturing of quality mailboxes & postal specialties. In business since 1988, PPU is ISO Certified and is officially licensed by the U.S. Postal Service to manufacture cluster box units and USPS approved commercial and residential mailboxes. Backed by a 200,000 square-foot state of the art facility and CAD-CAM capabilities, PPU is equipped to provide the best quality, pricing and service in the industry.

Postal Products Unlimited, Inc. logo

Postal Products Unlimited, Inc.

Click to Call

500 West Oklahoma Ave., Milwaukee, WI, 53207

Website

Download files for this product
Log in or create a free account to continue
  • Free, unlimited downloads
  • All formats: CAD, Revit, 3D, Specs
  • Manufacturer-provided, up-to-date files
550 Series Private Use Mailboxes preview 1
550 Rear Loading (N1004517) - 55 Door Unit, 11 High
550 Rear Loading (N1004517) - 55 Door Unit, 11 High
550 Series Private Use Mailboxes preview 1
CAD Preview
Mfg DWG Preview (Imperial)
550 Series Private Use Mailboxes

550 Rear Loading (N1004517) - 55 Door Unit, 11 High

The 550 series horizontal mailboxes were developed for private use within large institutions not serviced by the USPS like military bases, colleges, universities, and hotels. The heavy-gauge aluminum rear-loading mailboxes meet all USPS regulations except those pertaining to compartment size. The smaller compartment size allows for more mailboxes per module, and is perfect for areas with limited wall space. Each tenant door measures 6-3/8" x 3" and comes with a 5-pin cam lock, two keys, and a clear plastic window number slot for tenant identification.
550 Series Private Use Mailboxes

550 Rear Loading (N1004517) - 55 Door Unit, 11 High

The 550 series horizontal mailboxes were developed for private use within large institutions not serviced by the USPS like military bases, colleges, universities, and hotels. The heavy-gauge aluminum rear-loading mailboxes meet all USPS regulations except those pertaining to compartment size. The smaller compartment size allows for more mailboxes per module, and is perfect for areas with limited wall space. Each tenant door measures 6-3/8" x 3" and comes with a 5-pin cam lock, two keys, and a clear plastic window number slot for tenant identification.
