SAFTI FIRST® Safety And Fire Technology Inc.
SAFTI FIRST® Safety and Fire Technology Inc. has over 40 years of experience in testing, innovating and providing technologically advanced fire rated glass and framing systems. Our products are tested, certified, listed and labeled both by UL and Intertek/Warnock-Hersey. SAFTI FIRST is also the fire rated glass and framing division of O’Keeffe’s Inc., a leading USA manufacturer of architectural glass and metal products for 80 years.
GPX Fire Floor
GPX Fire Floor System: 120 Minute Fire Resistive Floor System
Largest tested and listed individual glass panel sizes to maximize the amount of daylight penetrating between floors while meeting fire rated requirements.Maximum individual panel area of 7,017.3 sq. in. (82-3/8 in. x 85-3/16 in.) fully supported and 4,763.9 sq. in. (67-7/8 in. x 70-3/16 in.) butt-glazed for 1 hour floor assemblies.Maximum individual panel area of 7,179.9 sq. in. (96-3/8 in. x 74-1/2 in.) fully supported and butt-glazed for 2 hour floor assemblies.Single glass unit comprised of custom SuperLite® II-XL combined with a tempered laminated walking surface and a structural steel framing grid. Both the glass unit and structural steel framing grid are manufactured and provided by SAFTI FIRST®.Meets ASTM E119 / UL 263 / CAN/ULC S101 and blocks smoke, flames and radiant heat up to 2 hours.Available with a durable, non-slip walking surface with loads up to 100 psf.Modular system with a top-loaded design for easy installation.Can be used in interior and exterior applications.Available in multiple frame finishes and glass make-ups.US Pat. No. 9,926,709.Standard 5 year limited warranty.USA manufactured for fast lead times and competitive pricing.
GPX Fire Floor
GPX Fire Floor System: 120 Minute Fire Resistive Floor System
Largest tested and listed individual glass panel sizes to maximize the amount of daylight penetrating between floors while meeting fire rated requirements.Maximum individual panel area of 7,017.3 sq. in. (82-3/8 in. x 85-3/16 in.) fully supported and 4,763.9 sq. in. (67-7/8 in. x 70-3/16 in.) butt-glazed for 1 hour floor assemblies.Maximum individual panel area of 7,179.9 sq. in. (96-3/8 in. x 74-1/2 in.) fully supported and butt-glazed for 2 hour floor assemblies.Single glass unit comprised of custom SuperLite® II-XL combined with a tempered laminated walking surface and a structural steel framing grid. Both the glass unit and structural steel framing grid are manufactured and provided by SAFTI FIRST®.Meets ASTM E119 / UL 263 / CAN/ULC S101 and blocks smoke, flames and radiant heat up to 2 hours.Available with a durable, non-slip walking surface with loads up to 100 psf.Modular system with a top-loaded design for easy installation.Can be used in interior and exterior applications.Available in multiple frame finishes and glass make-ups.US Pat. No. 9,926,709.Standard 5 year limited warranty.USA manufactured for fast lead times and competitive pricing.
